Description
| Design | 1-cylinder, 4-stroke engine |
| Displacement | 249 cm³ |
| Transmission | 5-speed |
| Fuel-mixture generation | Keihin EFI, throttle body 44 mm |
| EMS | Keihin EMS |
| Clutch primary drive teeth | 72 |
| Primary drive | 24:72 |
| Clutch | Wet multi-disc DS clutch, Brembo hydraulics |
| Engine cylinder | Single cylinder |
| Engine stroke | 4-Stroke |
| Frame design | Central double-cradle-type 25CrMo4 steel |
| Front brake | Disc brake |
| Rear brake | Disc brake |
| Rear subframe design | Aluminum-reinforced polyamide |
| Chain | 520, Non-sealed |
| Front suspension | WP XACT-USD (AER), Ø 48 mm |
| Rear suspension | WP XACT Monoshock with linkage |
| Suspension travel (front) | 310 mm |
| Suspension travel (rear) | 300 mm |
| Front suspension adjustment | Compression (high and low speed), rebound |
| Rear suspension setting | Compression and rebound adjustable |
| Seat height | 958 mm |
| Ground clearance | 343 mm |
| Tank capacity (approx.) | 14.5 l |
| Weight (without fuel) | 101.5 kg |
